B212 Nano
The new generation of the ultra compacts.
With an ultra compact design, B212 offers the basic features for a safe and accurate wheel balancing.
Space occupation is set to a minimum thanks to its small footprint, with a possibility to include all special features and options to balance any type of wheel to perfection.
It is suitable for tire shops, garages and mobile service vans.
The heart of the balancer is built around the TriSensor System, a FASEP exclusive design, and IFS System (integrated-flange shaft) for maximum centering accuracy.
Features :
- 2D gauge for automatic distance and diameter input and guided application of stick-on weights
- FASEP TriSensor 3 Piezo balancing system
- IFS (Integrated Flange Shaft)
- 16bit electronics
- low speed motor 98 rpm
- double LED display with multifunction keypad
Technical Features
- Automatic Digital wheel balancer
- Suitable for Car, Vans, SUVs and Light Trucks wheels
- 32-bit high-tech electronics G6.SMART electronic motor control
- 3Ph Motor with electronic control (inverter)
- Low Speed (98 RPM)
- Control Panel with multifunction keypad (double LED display)
- BASIC level wheel balancing software
- IFS Light flange system (max 75 kg)
- TRI.S3NSOR 3 Piezo sensors measuring system
- Shaft 40 mm
- Shaft height 665 mm
- Shaft length 210 mm
- 256 steps position sensor
- Compact cabinet
- Quick-Lock nut
- Electric Brake DCB (brake-in-position)
- Automatic Start-Stop
- Stop-on-top
- 2D automatic data input (distance+diameter)
- ABS weights holder (6 compartments for weights, 3 for cones, 1 for tools)
- Self Calibration with Calibration weight
- Self Diagnostic
- ALU programs (stick-on weights)
- ALU-SE / Alu-PAX program for application of stick-on weights
- MOTO program
- User Setup
- SPLIT program (Hidden Weights)
- MARS program for Static minimization
- STATS program
- FCC program
- Cones 42-98 mm
- Max wheel weight 75 kg
- Rim max diam. 10-26"
- Max wheel diam 864 mm (34") (with wheel-guard)
- Warranty On Center
Optional accessories
-
INST. SPIEG. c/o CLI (EQ.DIGITALE) -
EXT WARRANTY FOR DIGITAL WB -
EXT GARANZIA EQUILIBRATRICE DIGITALE -
Upgrade level FULL -
KIT PEDALE FRENO V548 - B212 -
CARTER COPRIRUOTA B2000 No Switch -
CARTER COPRIRUOTA B2000 Autostart -
AMSF-HD.40 PRO BIKE 2 TS CON PROLUNGA -
FLANGIA UNIVERSALE FUL-HD.40 Completa -
PINZA PIOMBI -
SET BOCCOLE DI CENTRAGGIO C1-C6 ø40 -
KIT KF.40 FUORISTRADA E FURGONI -
CF.40 CONO FUORISTRADA 94.5-137
